FFS 500 Pouch Machine
Form Fill Seal (FFS)

FFS 500 Pouch Machine

Mid-range FFS for pouches & pillow packs

Versatile vertical FFS platform for pillow and gusseted pouches up to 500 mm, with modular dosing.

Pouch width
Up to 500 mm
Output
Up to 45 pouches/min
Fill range
50 – 1000 g/ml
Power
415V / 3-phase
Talk to an engineer

Overview

Built to solve your packing challenge

Scaling up from sachets, the FFS 500 handles pillow, gusset and flat-bottom pouches with interchangeable dosing modules for powders, granules and liquids. Servo-driven film pull and a robust jaw assembly deliver accurate bag length and strong seals, while the PLC recipe system stores changeover settings for every SKU.

Key features

  • Servo film pull for accurate bag length
  • Interchangeable auger, cup and pump dosers
  • PLC recipe storage for fast changeover
  • Gusset, pillow and flat-bottom formats
  • Gas-flush ready for shelf-life extension

Typical applications

Snacks & namkeenDetergent powdersGrains & pulsesPet food
